Solución OBD completa y de banco para Continental ACM2.1 y ACM2.2

Flex versión 6.28.0.0 disponible ahora

A partir de ahora puedes programar las centralitas AdBlue Continental ACM2.1 y ACM2.2 en OBD Full y Bench sin necesidad de abrir la unidad.

Nueva actualización Flex para camiones y autobuses Mercedes.

No se utiliza ningún parche para la programación con estos nuevos protocolos, lo que garantiza la vigencia de la garantía de su vehículo. Solo necesita escribir la copia de seguridad completa original de las ECU para devolverlas a su estado original.

Nuevas ECU añadidas a la lista de vehículos Flex:

• ACM2.1 D1
• ACM2.1 D2
• ACM2.1 D3
• ACM2.1 D3 (protegido con contraseña)
• ACM2.1 D4
• ACM2.2 D2

Algunos de los vehículos admitidos:

• Camión Mercedes Actros 1851 12.8L OM471LA 510HP
• Camión Mercedes Arocs 1843 10.7L OM470 428HP
• Camión Mercedes Antos 2532 7.7L OM936 315HP
• Mercedes Autobús Citaro C2 10.7L OM470 394HP
• Mercedes Bus Turismo RHD 12.8L OM471LA 428HP
• Setra S515 HDH 12.8L OM471LA 470HP
• Freightliner Cascadia DD15 14.8L Detroit DD15 530HP

El nuevo protocolo está disponible para los siguientes paquetes de software:

OBD Full

• FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
• FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
• FLS0.5M – Flex Full SW Package Master
• FLS0.5S – Flex Full SW Package Slave

Para programar ACM2.1 y ACM2.2 en OBD Full necesitas comprar el cable FLX2.65 en www.magicmotorsport.shop o vía ticket

Bench

• FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
• FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
• FLS0.5M – Flex Full SW Package Master
• FLS0.5S – Flex Full SW Package Slave
• FLS0.10M – SW Flex Boot Infineon TC17xx / TC2xx Master
• FLS0.10S – SW Flex Boot Infineon TC17xx / TC2xx Slave

Protocolos recién agregados:

(OBD Full)

• Mercedes Trucks/Bus Continental ACM2.1 D1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D3 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D3 (PW protected) TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D4 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.2 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Tiempo de lectura: ~ 1,30 minutos Tiempo de escritura: ~ 2 minutos

(Bench)

• Mercedes Trucks/Bus Continental ACM2.1 D1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D3 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D3 (PW protected) TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D4 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.2 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Tiempo de lectura: ~ 1,30 minutos Tiempo de escritura: ~ 2 minutos

Corrección de errores:

• Fixed connection error with some versions of VAG Simos10.xx
• Add new HW version supported of Marelli 11GF
• Support added for new kind of checksum on Continental MCM and ACM
• Fixed CRC calculation on Marelli10JA

Mejoras de software:

• Added support for Melco E6T8008x MH8115
• Add support for Subaru Denso 112800 SH72531
• Updated protocol ACM2.1 (3520002) from Bench to Boot, in order to support also ACM2.1 D3 (PW protected) and D4

Haga clic aquí para descubrir la lista completa de vehículos admitidos.
