Second Batch of Flex Heavy-Duty Protocols

New Flex Update Out Now with the Second Batch of Flex Heavy-Duty Protocols

Second batch of protocols for heavy-duty vehicles released on Flex.

This new version of Flex (7.21.0.0) expands support to control units installed on industrial vehicles, agricultural machinery, and trucks, introducing new solutions in Bench and enriching compatibility in Boot for many ECUs that could once be programmed only via OBD or Bench.

This new release, dedicated to the second batch of protocols for heavy-duties, enables read and write operations, as well as full cloning – when available – of all memories inside control units, thanks to Bench and Boot modes.

Here’s the list of new available supports on Flex:

Denso 275700-4890 in Bench
Denso 275700-1201 in Bench
Landini Bosch MD1CS069 in Bench
Isuzu Bosch MD1CC878 in Bench
Isuzu Bosch MD1CE108 in Bench
Mercedes Truck Continental CPC3EVO in Boot
Freightliner Truck Continental CPC4 in Boot
Cummins CM2100A in Boot
Cummins CM2150C in Boot
Cummins CM2150E in Boot
Cummins CM2200A in Boot
Cummins CM2200B in Boot
Cummins CM2220A in Boot
Cummins CM2220B in Boot
Cummins CM2220C in Boot
Cummins CM2880 in Boot

This new protocols are available for the following software packages:

Bench/Boot

FLS0.5M – SW Flex Full Master
FLS0.5S – SW Flex Full Slave
FLS0.15M – SW Flex Heavy Duty OBD/Bench/Boot Master
FLS0.15S – SW Flex Heavy Duty OBD/Bench/Boot Slave

Newly added protocols:

(Bench)

Landini Bosch MD1CS069 TC299 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup
Isuzu Bosch MD1CC878 SPC58 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup
Isuzu Bosch MD1CE108 SPC58 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup
Kubota Denso 275700-1201 SH7058 Read/Write/Checksum Calculation Internal Flash, Read/Write External EEPROM, Full Backup
Kubota Denso 275700-4890 SH7058 Read/Write/Checksum Calculation Internal Flash, Read/Write External EEPROM, Full Backup

(Boot)

All Cummins CM2100A MPC5554 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2150C MPC5554 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2150E MPC5566 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2200A MPC5566 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2200B MPC5566 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2220A MPC5566 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2220B MPC5566 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2220C MPC5566 Read/Write/Checksum Calulation Internal Flash
All Cummins CM2880 SPC5644A Read/Write/Checksum Calulation Internal Flash
Mercedes Trucks Continental CPC3EVO MPC5674 Read/Write/Checksum Calulation Internal Flash, Read/Write External EEPROM, Full Backup
Freightliner Trucks Continental CPC4 TC1796 Read/Write/Checksum Calulation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
